Canon imagePROGRAF TM-300
Canon TM Series
Canon imagePROGRAF TM-300

Canon imagePROGRAF TM-300

3058C002

Canon imagePROGRAF TM-300

Brand:  Canon

Series:  TM

Model: imgPROGRAF

Type: Ink

Click Here to View the Brochure

Call For Price

SHARE
Share

Description

Features :

  • LUCIA TD Pigment Ink Set
  • Fast Printing
  • The TM Series large-format printers come equipped with several security features designed to help prevent leaks of confidential information:
  • The TM-300 is well suited for busy office environments as it is 60% quieter than previous imagePROGRAF printers and offers less distraction in the workplace.
  • The TM-300 features a 3″ color touchscreen operation panel making it easy to view printer information as well as perform simple operations.
  • A good fit for small offices, the compact TM-300 has a small footprint for a large format aqueous inkjet printer.
  • Wi-Fi Compatible
  • Print Head PF-06 is engineered to work with the printer’s high-speed carriage and high-frequency ink ejection to help facilitate fast printing.

Additional information

System Type

Ink Category

Brand

Model

Series

Width

Condition

Printer Type

5-Color 36-inch Printer

OS Compatibility

Windows 7 (32/64 bit), Windows 8.1 (32/64 bit),
Windows 10 (32/64 bit), Windows Server 2008 R2,
(32/64 bit), Windows Server 2012 (64 bit), Windows
Server 2012 R2 (64 bit), Windows Server 2016 (64 bit),
Macintosh OS X v10.10.5-v10.12x

Memory

Maximum Media Roll Diameter

5.9 (150mm)

Print Languages

SGRaster, HPGL/2, HP-RTL, JPEG, PDF

Physical Dimensions

42 x 51 x 35

Weight

approx.134 lbs (roll holder included, no inks, no print heads)

Printing Software Utilities

Accounting Manager, Apple AirPrint, Canon Print
Service, Device Management Console, Direct Print
& Share, Free Layout Plus, imagePROGRAF Printer
Driver for Windows®/Mac®, Media Configuration Tool,
PosterArtist Lite for Windows, Canon PRINT Inkjet
Selphy, Easy-Photo PrintEditor,† Optimized Driver
for AutoCAD, Free Layout

Print Head

PF-06

Technology

FINE (Photolithography Inkjet Nozzle Engineering)

Print Resolution (Max.)

2400 x 1200 dpi

Line Accuracy

±0.1% or Less

Minimum Line Weight

0.02 mm

Number of Nozzles

Matte Black: 5,120 Nozzles
Other Colors: 2,560 Nozzles per Color

Droplet Size

5 Picoliter

Nozzle Pitch (Head Resolution)

1200 dpi x Two Rows

Print Head Swath

1.07 inch

Ink Type

Pigment: Matte Black (MBK), Cyan (C), Magenta (M),
Yellow (Y), Black (BK)

Ink Tank

Shipped with Printer: MBK (130 ml), BK, C, M, Y (90 ml)
Replacement: PFI-120 (130 ml) or PFI-320 (300 ml)

Ink Supply Method

Tubing System with Sub-tanks for Continuous Ink Supply

Nozzle Recovery System

Non-firing Nozzle Detection and Compensation

Printer Controller

L-COA PRO

Media Feed

Roll Feed: One Roll, Top-loading, Front Output

Media Width

Roll Feed: 8"-36"(203 mm –914 mm)
Cut Sheet: 8"-36"(203 mm –914 mm)

Printable Margins

Roll Feed: All Sides: 0.12" (3 mm) or 0" for Borderless

Maximum Print Length (Single Page)†

Roll Feed: 59' (18 m)
Cut Sheet: 63" (1.6 m)

Borderless Printing Widths (Roll Media Only)

8", 10", 12", 14", 16", 17", 20", 24", 30", 36",
B4 (10.12"/257 mm), A3 (11.69"/297 mm),
A3+ (12.95"/329 mm), A2 (16.54"/420 mm),
B2 (20.28"/515 mm), A1 (23.39"/ 594 mm),
B1 (28.66"/ 728 mm), A0 (33.11"/841 mm)

Media Cutter

Durable Dual-Blade Rotary Cutter

Media Thickness

0.07 – 0.8 mm

Media Core Sizes

2" and 3" Core Adapters Included

Media Output

Basket (Standard)

Interface

Standard (Built-in): USB 2.0 Hi-Speed, 10/100/
1000Base-T/TX, Wireless LAN (IEEE 802.11 b/g /n)

Acoustic Noise

Operation: 44 dB (A) or Less
Standby: 35 dB (A) or Less
Acoustic Power: 6.0Bels or Less

Power Supply

AC 100–240V (50-60 Hz)

Power Consumption

Maximum: 69 W or Less
Standby: 3.6 W or Less
Power Off: 0.3 W or Less (Executive Order Compliant)

Certifications

Electrical Safety Regulations
C TUVus (U.S.A.), C TUVus (Canada)
Electromagnetic Interface Regulations
FCC Part 15B (U.S.A.), IC (Canada)
Radio Regulations
FCC Part 15C (U.S.A.), IC (Canada)
Environmental Certifications
ENERGY STAR® (Worldwide)

Operational Environment

Temperature: 59° – 86° F (15° – 30° C)
Relative Humidity: 10 – 80% (No Condensation)

Printer Dimensions (H x W x D) and Weight

(With Basket Opened)
42" x 51" x 34" Approx. 130 lb

Package Dimensions (H x W x D) and Weight

With Stand, Basket, and Pallet
38" x 58" x 36" Approx. 229 lb.

Options

• 2"/3" Roll Holder Set (RH2-35)
• PosterArtist
User-Replaceable Items
• Ink Tank (PFI-120/PFI-320)
• Print Head (PF-06)
• Maintenance Cartridge (MC-31)
• Cutter Blade (CT-08)

What’s In The Box

Printer, Basket, Stand, 2”/3” Core Media Spool (Adapters Included), Power Cord, Tools and Screws, Print
Head, Maintenance Cartridge (Installed),
5 Ink Tanks (130 ml: MBK, 90 ml: BK/C/M/Y),
Sample Heavyweight Coated Paper (A2/2 Sheets),
Ethernet Card (built-in), USB 2.0 High-speed Interface,
USB Connection Sheet, iWR Service Terms Leaflet,
User Manual, Quick Setup Guide, User Software CD
for Windows (Printer Driver Utilities),
PosterArtist Lite CD, User Registration Card
