Canon imagePROGRAF TA-30
Canon imagePROGRAF-30
Canon imagePROGRAF TA-30

Canon imagePROGRAF TA-30

3661C005AA

**This model has been discontinued**

Brand:  Canon

Series: TA

Model: imagePROGRAF TA-30

Type: Ink

SHARE
Share

Description

Bring your printing in house with the Canon imagePROGRAF TA-30 large format printer. With uncompromising quality from the #3 patent holder in the U.S., this multipurpose 36″ printer, offers a cost-efficient, easy-to-use solution built to stimulate workflow and productivity for small businesses and first-time large format print users. The TA Series ships with free poster/marketing creation software and a Print Plug-in for Microsoft Office – the software tools you need to bring your business to the next level.

Print More Out of the Box*
The TA Series ship with 164% more ink than the comparable HP and 157% more ink than the comparable Epson currently offer. 330ml ink in total – over a $250 value!

Low Cost of Operation
Economy Print Mode (Fast (Q5)) allows for up to 40% less ink to be used during printing than standard mode Q3 – helping to lower your operation costs.

Unparalleled Speed
Print 113 24 x 36 posters per hour1. That’s 43 more posters than the HP T130 can print!*

Print Outdoor Posters
Unlike the HP DesignJet printers*, the TA Series use pigment ink to produce weather-resistant posters.

The Perfect Print
With Canon’s advanced Air Feeding System, paper is kept flat during printing – helping to make consistent prints every time!

Security Feature
The TA Series large-format printers come equipped with several security features designed to help prevent leaks of confidential information:
802.1x: Helps ensure information is secure when passing over a network by providing authentication to devices attempting to connect to the network.
SSL/TLS: Allows sensitive information being sent via an internet connection to be sent securely for data being passed between two systems.
IPSec: Authenticates and encrypts data passed over IP networks.

Minimize Disruption in the Workplace
The TA is the quietest printer in this market.*

More Paper. More Printing
The TA has the ability to utilize long rolls (5.9″ in diameter) and a wide variety of media.

Compact Design
The TA-30’s small footprint is perfect for any office or desktop.

Wi-Fi Printing3
Print mobile from almost anywhere in the office or jobsite.

Nonstop Printing
The Sub-Ink Tank System lets you change empty cartridges while the printer continues to print allowing you to use virtually all of the available ink in the tank before having to replace it.

Virtually No Printing Limits
Print borderless on all media sizes – the competition can’t do this!*

What’s In The Box

  • Canon imagePROGRAF TA-30
  • Printer Stand2″ Core Media Spool
  • US AC Power Cable
  • Tools and Screws
  • Print Head PF-06
  • Maintenance Cartridge (Installed)
  • 6 Ink Tanks (55 ml each: MBK x2, C/M/Y/BK)
  • Ethernet Card (built-in)
  • USB 2.0 High-speed Interface
  • USB Connection Sheet
  • iWR Service Terms Leaflet
  • User Manual
  • Quick Setup Guide
  • User Software CD for Windows (Printer Driver Utilities)
  • User Registration Card
  • Media Guide

Here are some of Canon’s Large Format Printers

Additional information

Weight 1 lbs
Brand

Series

TA

Model

imagePROGRAF

Condition

Type

Ink

Printer Type

5-Color 36-inch Printer

OS Compatibility

Windows 7 (32/64 bit), Windows 8.1 (32/64 bit),
Windows 10 (32/64 bit), Windows Server 2008
R2, (32/64 bit), Windows Server 2012 (64 bit),
Windows Server 2012 R2 (64 bit), Windows Server
2016 (64 bit), Macintosh OS X v10.10.5-v10.12x

Width

Maximum Media Roll Diameter

5.9” (150mm)

Printing Software Utilities

Accounting Manager, Canon Print Service, Device
Management Console, Direct Print & Share,
Free Layout Plus, imagePROGRAF Printer Driver
for Windows®/Mac®, Media Configuration Tool,
PosterArtist Lite for Windows, Canon PRINT Inkjet
Selphy, Easy-Photo PrintEditor, Optimized Driver
for AutoCAD, Free Layout

Stand

Yes, No

Print Head

PF-06

Line Accuracy*

±0.1% or Less

Number of Nozzles

Matte Black: 5,120 Nozzles
Other Colors: 2,560 Nozzles Per Color

Ink Type

Pigment: Matte Black (MBK), Cyan (C),
Magenta (M), Yellow (Y), Black (BK

Ink Tank

Shipped with Printer: (2) MBK, BK, C, M, Y (55 ml)
Replacement: PFI-030 (55 ml)

Ink Supply Method

Tubing System with Sub-tanks for
Continuous Ink Supply

Nozzle Recovery System

Non-firing Nozzle Detection and Compensation

Printer Controller

L-COA PRO

Media Feed

Roll Feed: One Roll, Top-loading, Front Output
Cut Sheet: Top-loading, Front Output

Max Resolution

Memory

Media Width

Roll Feed: 8" – 36" (203 mm – 914 mm)
Cut Sheet: 8" – 17" (203 mm – 432 mm)

Printable Margins

Roll Feed: All Sides: 3 mm or 0" for Borderless
Cut Sheet: Top: 3 mm; Bottom: 20 mm; Side: 3 mm

Borderless Printing Widths (Roll Media Only)

8" – 36"

Media Cutter

Rotary Cutter

Media Thickness

0.07 – 0.8 mm

Media Core Sizes

2" and 3" Core Adapters

Print Language

Printer: SGRaster, HP-GL/2, HP RTL, JPEG

Media Output

Basket

Interface

Standard (Built-in): USB 2.0 Hi-Speed,
10/100/1000Base-T/TX, Wireless LAN
(IEEE 802.3 b/g /n)■

Acoustic Noise

Operation: 42 dB (A) or Less
Standby: 35 dB (A) or Less
Acoustic Power: 5.8 Bels or Less

Power Supply

AC 100 – 240V (50 – 60 Hz)

Power Consumption

Maximum: 59 W or Less
Standby: 3.6 W or Less
Power Off: 0.3 W or Less
(Executive Order Compliant)

Certifications

Electrical Safety Regulations
C TUVus (U.S.A.)
Electromagnetic Interface Regulations
FCC Part 15B (U.S.A.)
Radio Regulations
FCC Part 15C (U.S.A.)
Environmental Certifications
ENERGY STAR® (Worldwide)

Operational Environment

Temperature: 59° – 86° F (15° – 30° C)
Relative Humidity: 10 – 80% (No Condensation

Printer Dimensions (H x W x D) and Weight

With Stand (Basket opened):
42” x 51” x 35”; Approx. 117 lb

Package Dimensions (H x W x D) and Weight

With Stand, Basket, and Pallet:
32” x 59” x 36”; Approx. 199 lb

Options

2”/3” Roll Holder Set (RH2-35)
• PosterArtist
User-Replaceable Items
• Ink Tank (PFI-030)
• Print Head (PF-06)
• Maintenance Cartridge (MC-31)
• Cutter Blade (CT-08)

What’s In The Box

Printer, Power Cord, Tools and Screws, Print Head,
Maintenance Cartridge (Installed), 6 Ink Tanks
(55 ml: MBK x 2/BK/C/M/Y), Ethernet Card
(built-in), USB 2.0 High-speed Interface, USB
Connection Sheet, iWR Service Terms Leaflet,
User Manual, Quick Setup Guide, User Software
CD for Windows (Printer Driver Utilities), User
Registration Card
