Weight |
100 lbs |
Series |
Pro
|
Model |
imagePROGRAF
|
Type |
Ink
|
Printer Type |
8 Colour 60 – inch / 1524mm
|
OS Compatibility |
Microsoft Windows: 32 Bit, Vista, 7,8, 8.1,10
Server 2008, 64 Bit: Vista, 7,8, 8.1,10,
Server 2008/R2, Server 2012/R2, Windows Server 2019
Apple Macintosh: OS X 10.11.6, macOS 10.12~macOS 10.15
|
Physical Dimensions |
46.0 (H) x 78.7 (W) x 38.7 (D) (with basket open)
|
Weight |
approx.302 lbs (roll holder included, no inks, no print heads)
|
Software Included |
imagePROGRAF PRO Printer Driver
Other software available as Download from Web
|
Brand |
Canon
|
Print Technology |
Canon Bubblejet on Demand 12 colours integrated type
(12 chips per print head x 1 print head)
|
Memory |
3 GB
|
Max Resolution |
2400 x 1200 dpi
|
Number of Nozzles |
18,432 nozzles (1536 nozzles x 4 colours,
3072 nozzles x 4 colours)
|
Line Accuracy |
±0.1% or less
User adjustments necessary. Printing environment and
media must match those used for the adjustments.
CAD paper required: Plain paper, CAD tracing paper,
coated paper, CAD translucent matte film only
|
Nozzle Pitch |
600 dpi x 2 includes Non-firing nozzle detection and
compensation system
|
Ink Droplet Size |
minimum 4 pl per colour
|
Ink Capacity |
Sales Ink: 160ml/330ml/700ml
Bundled Starter Ink: 330ml
|
Ink Type |
Pigment inks – Black, Matte Black, Cyan, Magenta, Yellow,
Photo Cyan, Photo Magenta, Grey
|
Printer Languages |
SG Raster (Swift Graphic Raster), PDF (Ver.1.7), JPEG
(Ver. JFIF 1.02)
|
Standard Interfaces |
USB A Port: USB Memory Direct Print for JPEG/PDF files
USB B Port: Built-in Hi-Speed USB 2.0
Ethernet: 10/100/1000 base-T
Wireless LAN: IEEE802.11n/IEEE802.11g/IEEE802.11b
*Please refer to user manual how to activate/deactivate the wireless LAN
|
Hard Drive |
500GB (Encrypted HDD)
|
PRINT TIME FOR A0 PAGE SIZE |
Media Type Print Mode: Print Time
Plain Paper Print Mode – Print Time
Fast 1:21 min
Standard 2:24 min
Coated Paper Print Mode – Print Time
Standard 2:24 min
High Quality 5.34 min
Glossy Photo Paper Print Mode – Print Time
Standard 4:44 min
High Quality 5:34 min
|
Media Feed and Output |
Upper Roll Paper: One Roll, Front-loading, Front Output
Lower Roll Paper: One Roll, Front-loading, Front Output
Cut Sheet: Front-loading, Front Output (Manual feed
using media locking lever)
|
Media Width |
Roll paper: 152.4 -1524 mm
Cut sheet: 152.4 – 1524 mm
|
Media Thickness |
Roll/Cut: 0.07 – 0.8 mm
|
Minimum Printable Length |
203.2 mm
|
Maximum Printable Length |
Roll paper: 18 m (Varies according to the OS and
application)
Cut sheet: 2133.6mm
|
Maximum Media Roll Diameter |
170 mm
|
Media Core Size |
Internal diameter of roll core: 2”/3”
|
Margins Recommended area |
Roll paper: Top: 20 mm, Bottom: 3 mm, Side: 3 mm
Cut sheet: Top: 20 mm, Bottom: 20 mm, Side: 3 mm
|
Margins Printable area |
Roll paper: Top: 3 mm, Bottom: 3 mm, Side: 3 mm
Roll paper (borderless): Top: 0 mm, Bottom: 0 mm,
Side: 0 mm
Cut sheet: Top: 3 mm, Bottom: 20 mm, Side: 3 mm
|
Media Feed Capacity |
Roll Paper: Two rolls. Automatic switching is possible.
Cut Sheet: 1 sheet
|
Media Take-up roll unit |
Dual direction roll take up unit allowing print surface to be
wound inside or outside of the roll
|
Borderless Printing Width (Roll Only) |
515mm(JIS B2), 728mm(JIS B1), 1030mm(JIS B0),
594mm(ISO A1), 841mm(ISO A0), 10”,14”, 17”, 24’’, 36’’,
42”, 44”, 50”, 54”, 60”, 257mm(JIS B4)*, 297mm(ISO
A3)*, 329mm(ISO A3+)*, 420mm(ISO A2)*,6’’, 8”*,
12’’.16”*,20’’, 22’’, 30”*, 300mm*,500mm, 600mm,
800mm, 1000mm and custom roll width (152.4~1524mm)
*Some environmental conditions may not produce the desired result
|
Maximum number of delivered prints |
Standard position: 1 sheet
Flat position: A2 landscape, glossy paper less than 10 sheets,
Coated paper less than 20 sheets (excludes strong curled
condition)
|
Physical Dimensions WxDxH (mm) and Weight (Kg) |
1999 x 984 x 1168 mm (Basket Open)
1999 x 766 x 1168 mm (Basket Closed)
169kg (including Roll Holder Set and Roll unit, excluding
ink and print heads)
|
Packaged Dimensions WxDxH (mm) and Weight (Kg) |
Printer (Main unit with pallet): 2227 x 915 x 1022 mm
approx. 212kg
Roll Unit: 2133 x 562 x 461 mm
42kg
|
Power Supply |
AC 100-240V (50-60Hz)
|
Power Consumption |
Operation: 109 W or less
Sleep mode: 2.1W or less
Default setting for the time to enter the Sleep mode:
Approx. 5 Minutes
Power off: 0.3 W or less
|
Operating Environment |
Temperature: 15~30oC, Humidity: 10~80% RH
(no dew condensation)
|
Accoustic Noise (Power/Pressure) |
Operation: approx.49 dB (A) (Glossy paper, Print priority:
Standard)
Standby: 35 dB (A) or less
Operation: 6.7 Bels or less (Glossy paper, Image, Print
priority: Standard) (Measured on ISO 7779 standard)
|
What's in the Box? |
Printer, 1print heads, 3 inch paper core attachment,
Power Cable, 1 set of starter ink tanks, Set up guide,
Safety/Standard Environment leaflet, User software CDROM (Win), PosterArtist Lite CD-ROM, EU Biocide Sheet,
Eurasian Economic Union Sheet, Important Information
Sheet
|
Optional Items |
2/3” Roll Holder: RH2-66
Roll Unit: RU-63
|
User Replaceable Items |
Ink Tank: PFl-1100 (160ml), PFl-1300 (330ml),
PFl-1700 (700ml)
Print Head: PF-10
Cutter Blade: CT-07
Maintenance Cartridge: MC-30
|
