| Weight |
100 lbs |
| Brand |
Canon
|
| Type |
Ink
|
| Model |
imagePROGRAF
|
| Width |
60"
|
| Series |
Pro
|
| Condition |
New
|
| Printer Type |
12 Colour 60"/1524mm
|
| OS Compatibility |
Microsoft Windows 32 Bit: Vista, 7, 8, 8.1, 10, Server 2008,
64 Bit: Vista, 7, 8, 8.1, 10, Server 2008/R2, Server 2012/R2
Apple Macintosh: OSX 10.7.5 ~ 10.11
|
| Maximum Media Roll Diameter |
6.7 (170mm)
|
| Print Languages |
SG Raster (Swift Graphic Raster), PDF (Ver.1.7),
JPEG (Ver. JFIF 1.02)
|
| Physical Dimensions |
46.0 (H) x 78.7 (W) x 38.7 (D) (with basket open)
|
| Weight |
approx.368 lbs (roll holder included, no inks, no print heads)
|
| Print Technology |
Canon Bubblejet on Demand 12 colours integrated type
(12 chips per print head x 1 print head)
|
| Print Resolution |
2,400 x 1200 dpi
|
| Number of Nozzles |
18,432 nozzles (1536 nozzles x 12 colour)
|
| Line Accuracy |
±0.1% or less
User adjustments necessary. Printing environment and
media must match those used for the adjustments.
CAD paper required: Plain paper, CAD tracing paper,
coated paper, CAD translucent matte film only
|
| Nozzle Pitch |
600 dpi x 2 includes Non-firing nozzle detection and
compensation system
|
| Ink Droplet Size |
minimum 4 pl per colour
|
| Ink Capacity |
Sales Ink: 160ml/330ml/700ml
Bundled Starter Ink: 330ml
|
| Ink Type |
Pigment inks – Black, Matte Black, Cyan, Magenta, Yellow,
Photo Cyan, Photo Magenta, Grey, Photo Grey, Red, Blue,
Chroma Optimiser
|
| Standard Interfaces |
USB A Port: USB Memory Direct Print for JPEG/PDF files
USB B Port: Built-in Hi-Speed USB 2.0
Ethernet: 10/100/1000 base-T
Wireless LAN: IEEE802.11n/IEEE802.11g/IEEE802.11b
*Please refer to user manual how to activate/deactivate
the wireless LAN
|
| Memory |
3 GB
|
| Hard Drive |
320 GB
|
| PRINT TIME FOR A0 PAGE SIZE |
Plain Paper Print Mode – Print Time
Fast 1:37 min
Standard 2:51 min
Coated Paper Print Mode – Print Time
Standard 2:51 min
High Quality 5:36 min
Glossy Photo Paper Print Mode – Print Time
Standard 6:21 min
High Quality 10:05 min
|
| Media Feed and Output |
Upper Roll Paper: One Roll, Front-loading, Front Output
Lower Roll Paper: One Roll, Front-loading, Front Output
Cut Sheet: Front-loading, Front Output
(Manual feed using media locking lever)
|
| Media Width |
Roll paper: 203.2 -1524 mm
Cut sheet: 203.2 – 1524 mm
|
| Media Thickness |
Roll/Cut: 0.07 – 0.8 mm
|
| Minimum Printable Length |
203.2 mm
|
| Maximum Printable Length |
Roll paper: 18 m
(Varies according to the OS and application)
Cut sheet: 1.6 m
|
| Media Core Size |
Internal diameter of roll core: 2"/3"
|
| Margins Recommended area |
Roll paper: Top: 20 mm, Bottom: 3 mm, Side: 3 mm
Cut sheet: Top: 20 mm, Bottom: 20 mm, Side: 3 mm
|
| Margins Printable area |
Roll paper: Top: 3 mm, Bottom: 3 mm, Side: 3 mm
Roll paper (borderless): Top: 0 mm, Bottom: 0 mm,
Side: 0 mm
Cut sheet: Top: 3 mm, Bottom: 20 mm, Side: 3 mm
|
| Media Feed Capacity |
Roll Paper: Two rolls. Automatic switching is possible.
Cut Sheet: 1 sheet
|
| Media Take-up roll unit |
Dual direction roll take up unit allowing print surface to be
wound inside or outside of the roll
|
| Borderless Printing Width (Roll Only) |
515 mm(JIS B2), 728 mm(JIS B1), 1030 mm(JIS B0),
594 mm(ISO A1), 841 mm(ISO A0), 10", 14", 17", 24", 36",
42", 44", 50", 54", 60", 257 mm(JIS B4)*,
297 mm(ISO A3)*, 329 mm(ISO A3+)*, 420 mm(ISO A2)*,
8"*, 16"*, 30"*, 300 mm*
*Some environmental conditions may not produce the
desired result
|
| Maximum number of delivered prints |
Standard position: 1 sheet
Flat position: A2 landscape, glossy paper less than
10 sheets, Coated paper less than 20 sheets
(excludes strong curled condition)
|
| Physical Dimensions WxDxH (mm) and Weight (Kg) |
1999 x 984 x 1168 mm (Basket Open)
1999 x 766 x 1168 mm (Basket Closed)
167 kg (including Roll Holder Set and Roll unit, excluding
ink and print heads)
|
| Packaged Dimensions WxDxH (mm) and Weight (Kg) |
Printer (Main unit with pallet): 2227 x 915 x 1022 mm
210 kg
Roll Unit: 2133 x 562 x 461 mm
40 kg
|
| Power Supply |
AC 100-240V (50-60Hz)
|
| Power Consumption |
Operation: 103 W or less
Sleep mode: 3.6W or less
Default setting for the time to enter the Sleep mode:
Approx. 5 Minutes
Power off: 0.3 W or less
|
| Operating Environment |
Temperature: 15~30°C, Humidity: 10~80% RH (no dew
condensation)
|
| Accoustic Noise (Power/ Pressure) |
Operation: 50 dB (A) (Glossy paper, Print priority:
Standard)
Standby: 35 dB (A) or less
Operation: 6.7 Bels or less (Glossy paper, Image, Print
priority: Standard) (Measured on ISO 7779 standard)
|
| Enviroment Certificates |
International Energy Star Program (WW), RoHS
|
| What's in the Box? |
Printer, Roll Unit, 1 x Print Head, 1 x Maintenance Cartridge,
3” Paper Core Attachment, EU & UK Power Cable, 1 Set
of Starter Ink Tanks, Set Up Guide, Safety/Standard
Environment Leaflet, User Software CD-ROM
(OSX/Windows), PosterArtist Lite CD-ROM, EU Biocide
Sheet, Eurasian Economic Union Sheet, Important
Information Sheet, Quick Guide and Printhead
Alignment Sheet
|
| Software Included |
imagePROGRAF PRO Printer Driver, Print Plug-In for
Office, Quick Utility Toolbox and PosterArtist Lite
Other software available as Download from Web
|
| Optional Items |
2/3" Roll Holder: RH2-45
|
