| Weight |
223 lbs |
| Brand |
Canon
|
| Series |
Pro
|
| Model |
imagePROGRAF
|
| Type |
Ink
|
| OS Compatibility |
Microsoft Windows: 32 Bit, Vista, 7,8, 8.1,10 Server 2008, 64 Bit: Vista, 7,8, 8.1,10, Server 2008/R2, Server 2012/R2, Windows Server 2019 Apple Macintosh: OS X 10.11.6, macOS 10.12~macOS 10.15
|
| Memory |
3 GB
|
| Ink Capacity |
Sales Ink: 160ml/330ml/700ml Bundled Starter Ink: 160ml
|
| Hard Drive |
500GB (Encrypted HDD)
|
| Maximum Roll Print Length |
Roll Feed – 59' (18 meters)**
|
| Physical DimensionsPhysical Dimensions |
46.0 (H) x 43.7 (W) x 38.7 (D) (with basket open)
|
| Weight |
approx.223 lbs (roll holder included, no inks, no print heads)
|
| Software Included |
imagePROGRAF PRO Printer Driver and PosterArtist Lite Other software available as Download from Web.
|
| Printer Type |
12 Colour 24”/610mm
|
| Print Technology |
Canon Bubblejet on Demand 12 colours integrated type (12 chips per print head x 1 print head)
|
| Print Resolution |
2,400 x 1200 dpi
|
| Number of Nozzles |
18,432 nozzles (1536 nozzles x 12 colours)
|
| Line Accuracy |
±0.1% or less User adjustments necessary. Printing environment and media must match those used for the adjustments. CAD paper required: Plain paper, CAD tracing paper, coated paper, CAD translucent matte film only
|
| Nozzle Pitch |
600 dpi x 2 includes Non-firing nozzle detection and compensation system
|
| Ink Droplet Size |
minimum 4 pl per colour
|
| Printer Languages |
SG Raster (Swift Graphic Raster), PDF (Ver.1.7), JPEG (Ver. JFIF 1.02)
|
| Standard Interfaces |
USB A Port: USB Memory Direct Print for JPEG/PDF files USB B Port: Built-in Hi-Speed USB 2.0 Ethernet: 10/100/1000 base-T Wireless LAN: IEEE802.11n/IEEE802.11g/IEEE802.11b *Please refer to user manual how to activate/deactivate the wireless LAN
|
| PRINT TIME FOR A1 PAGE SIZE |
Media Type Print Mode: Print Time Plain Paper Print Mode – Print Time Fast 00:58 min Standard 01:38 min Coated Paper Print Mode – Print Time Standard 01:38 min High Quality 03:11 min Glossy Photo Paper Print Mode – Print Time Standard 03:11 min High Quality 05:02 min
|
| Media Feed and Output |
Upper Roll Paper: One Roll, Front-loading, Front Output Lower Roll Paper: One Roll, Front-loading, Front Output Cut Sheet: Front-loading, Front Output (Manual feed using media locking lever)
|
| Media Width |
Roll paper: 152.4 – 610mm Cut sheet: 152.4 – 610mm
|
| Media Thickness |
Roll/Cut: 0.07 – 0.8 mm
|
| Minimum Printable Length |
203.2 mm
|
| Maximum Printable Length |
Roll paper: 18 m (Varies according to the OS and application) Cut sheet: 2133.6mm
|
| Maximum Media Roll Diameter |
170 mm
|
| Media Core Size |
Internal diameter of roll core: 2”/3”
|
| Margins Recommended area |
Roll paper: Top: 20 mm, Bottom: 3 mm, Side: 3 mm Cut sheet: Top: 20 mm, Bottom: 20 mm, Side: 3 mm
|
| Margins Printable area |
Roll paper: Top: 3 mm, Bottom: 3 mm, Side: 3 mm Roll paper (borderless): Top: 0 mm, Bottom: 0 mm, Side: 0 mm Cut sheet: Top: 3 mm, Bottom: 20 mm, Side: 3 mm
|
| Media Feed Capacity |
Roll Paper: Two rolls. Automatic switching is possible. Cut Sheet: 1 sheet
|
| Media Take-up roll unit |
Dual direction roll take up unit allowing print surface to be wound inside or outside of the roll
|
| Borderless Printing Width (Roll Only) |
515mm(JIS B2), 594mm(ISO A1), 10”, 14”, 17”, 24”, 257mm(JIS B4)*, 297mm(ISO A3)*, 329mm (ISO A3+)*, 420mm(ISO A2)*, 6’’,8”*, 12’’,16”*, 20’’, 22’’, 30”*, 300mm*, 500mm, 600mm and custom roll width (154.2-610mm) *Some environmental conditions may not produce the desired result
|
| Maximum number of delivered prints |
Standard position: 1 sheet Flat position: A2 landscape, glossy paper less than 10 sheets, Coated paper less than 20 sheets (excludes strong curled condition)
|
| Physical Dimensions WxDxH (mm) and Weight (Kg) |
1110 x 984 x 1168 mm (Basket Open) 1110 x 766 x 1168 mm (Basket Closed) 119 kg (including Roll Holder Set and Roll unit, excluding ink and print heads)
|
| Packaged Dimensions WxDxH (mm) and Weight (Kg) |
Printer (Main unit with pallet): 1324 x 902 x 1042 mm 124kg Roll Unit: 1244 x 562 x 461 mm 26kg
|
| Power Supply |
AC 100-240V (50-60Hz)
|
| Power Consumption |
Operation: 93 W or less Sleep mode: 2.0W or less Default setting for the time to enter the Sleep mode: Approx. 5 Minutes Power off: 0.3 W or less
|
| Operating Environment |
Temperature: 15~30o, Humidity: 10~80% RH (no dew condensation)
|
| Accoustic Noise (Power/Pressure) |
Operation: approx. 46 dB (A) (Glossy paper, Print priority: Standard) Standby: 35 dB (A) or less Operation: 6.4 Bels or less (Glossy paper, Image, Print priority: Standard) (Measured on ISO 7779 standard)
|
| Certificates |
TUV, CB
|
| What’s in the Box? |
Printer, 1print heads, 3 inch paper core attachment, Power Cable, 1 set of starter ink tanks, Set up guide, Safety/ Standard Environment leaflet, User software CD-ROM (Win), PosterArtist Lite CD-ROM, EU Biocide Sheet, Eurasian Economic Union Sheet, Important Information Sheet
|
| Optional Items |
Printer Stand: SD-21 2/3” Roll Holder: RH2-29 Roll unit: RU-23
|
| User Replaceable Items |
Ink Tank: PFl-1100 (160ml), PFl-1300 (330ml), PFl-1700 (700ml) Print Head: PF-10 Cutter Blade: CT-07 Maintenance Cartridge: MC-30
|
